YTH CI
YTH CI
Impellerpumpe 5 bar
with cyclone filter
cyclonic filter
The cyclone filter system cleans the coolant of impurities
5 bar
Pressure and volume flow are generated in the impeller pump using the centrifugal force principle
Our YTH-CI is available in many variants
| type designation | engine type | Motor power (kW) | Feed quantity (L / min) | Maximaldruck (bar) | weight (kg) |
|---|---|---|---|---|---|
| YTH1500AE-I155C | 400 V / 50 Hz | 1,5 | 150 | 5 | 43 |
| YTH3700AE-I305C | 400 V / 50 Hz | 4,0 | 300 | 5 | 70 |
| YTH1500AC-I155C | 200V / 50 Hz | 1,5 | 150 | 5 | 39 |
| YTH3700AC-I305C | 200V / 50 Hz | 3,7 | 300 | 5 | 70 |
type key
How to find out which YTH pump you need
TOP-YTH - C
